FORCE X
Chargement...
Non-contractual images
Models available
FORCE X
FORCE X
Technical Specifications
 MOTOR |
|
| Bore x Stroke (mm) | 51,0*54,0 |
| Compression ratio | 9,3 : 1 |
| Cooling system | Air-cooled |
| Displacement (cc) | 110 |
| Engine type | Single cylinder, 4-stroke, SOHC, 2-valves |
| Fuel delivery | Carburetor |
| Ignition system | CDI |
| Lubrification system | Wet sump |
| Maximum power (hp / rpm) | NC |
| Maximum torque (N.m / rpm) | 9 / 5500 |
| Starter system | Kick and electric starter |
 CHASSIS |
|
| Frame | Backbone |
| Front brake | Simple disk |
| Front suspension system | Telescopic fork |
| Front tyre | 70/90-17 |
| Rear brake | Drum |
| Rear suspension system | Swingarm |
| Rear tyre | 80/90-17 |
| Wheels | Cast |
 DIMENSIONS |
|
| Min ground clearance (mm) | 125 |
| Overall dim - L x w x h (mm) | 1895*675*1030 |
| Seat height (mm) | 765 |
| Wheelbase (mm) | 1200 |
 TRANSMISSION |
|
| Transmission system | 4-speed constant mesh |
 WEIGHT/CAPACITIES |
|
| Dry weight (kg) | 97 |
| Fuel tank capacity (L) | 4 |
| Number of seats | 2 |
 WARRANTY |
|
| Manufacturer Warranty | 12 months / 12000 km |
| Retail Network | Yamaha |
Equipments
EQUIPMENT |
|
| Cast wheels | Yes |
| Disc brake | Yes |
| Electric starter | Yes |
| Kick starter | Yes |
